Authentication Method Biometric
Dust/ Water Resistance IP65 / IK09
Memory Max Users card (1:1) / (1:N) 20,000
Fingerprint
(Base on one finger
enrollment per user)
1:1 20,000
1:N 15,000
Face
(Base on five Face
enrollment per user)
1:1 X
1:N X
Iris
(Base on 2 eyes (L/R)
enrollment per user)
1:1 X
1:N X
Templates Fingerprint 1:1 40,000
1:N 30,000
MAX Templates per Finger 2
MAX Finger per User 10
Face 1:1 X
1:N X
MAX Templates per Finger X
Iris 1:1 X
1:N X
MAX Templates per Eyes X
MAX Templates per User X
Logs 64,000
Images X
Communication with server TCP/IP
other X
Wireless LAN(Wi-Fi) X
Wiegand OUT O
RS232 O
RS485 OSDP
Wiegand IN O
Display LCD 2.8″Color
Backlight 0
Embedded Camera X
Card 125khz-EM O
HID Prox O
HID iclass O
13.56MHz Smart Card O
Keypad O
Function keys 10
Door Phone X
FP Sensor (Platen Area) 16 X 20 mm
Resolution 500dpi
Dimension (W) X (H) X (D) mm 88 X 175 X 43.5
FRR /FAR 0.1% / 0.0001%
Operating Temperature -20 ~ 60℃
Opertating Software (Server solution) UNIS
